Block Cutting Segment And Blade For Granite PRODUCT FEATURES: 1 The blade has good sharpness and high efficiency at the
Send your inquiryDESCRIPTION
Basic Info.
Model NO. | stone cutting segment |
Use | Saw Blade, Grinding Wheel, Drill Bit Ect. |
Application | Granite, Basalt, Sandstone, Marble Ect. |
Transport Package | Cartons, Woodcase and Others |
Specification | 350-3500mm |
Trademark | WL |
Origin | Quanzhou |
Production Capacity | 300000PCS/Day |
Product Description
Block Cutting Segment And Blade For Granite
PRODUCT FEATURES:
1 The blade has good sharpness and high efficiency at the process of cutting,meanwhile,it has a long lifespan2 Good cutting result:smooth cutting,flat surface and even size3 Stable cutting,narrow cutting gap,stone waste reduction 4 M-Shape segment is easy for diamond openingWANLONG Diamond Tools Co., Ltd looks forward to establishing a mutually beneficial relationship with all of you.
Diameter(mm) | Width(mm) | Height (mm) | Length(mm) | Number ofsegment (pcs) | Inner hole ofcore (mm) | Thickness of core (mm) |
200 | 3.2 | 10,12,15 | 40 | 14 | 50,60 | 1.8 |
250 | 3.2 | 10,12,15 | 40 | 17 | 50,60 | 2.2 |
300 | 3.2 | 10,12,15 | 40 | 21 | 50,60 | 2.2 |
350 | 3.2 | 10,12,15,20 | 40 | 24 | 50,60 | 2.2 |
400 | 3.6 | 10,12,15,20 | 40 | 28 | 50,60 | 2.6 |
450 | 4 | 10,12,15,20 | 40 | 32 | 50,60 | 3 |
500 | 4 | 10,12,15,20 | 40 | 36 | 50,60 | 3 |
550 | 4.6 | 10,12,15,20 | 40 | 40 | 50,60 | 3.6 |
600 | 4.6 | 10,12,15,20 | 40 | 42 | 50,60 | 3.6 |
700 | 5 | 10,12,15,20 | 40 | 52 | 50,60 | 4 |
750 | 5.5 | 10,12,15,20 | 40 | 56 | 50,60 | 4.5 |
800 | 5.5 | 10,12,15,20 | 40 | 46 | 50,60 | 4.5 |
850 | 5.5 | 10,12,15,20 | 40 | 50 | 50,60 | 4.5 |
Diameter(mm) | Steel core(mm) | Head size(mm) | No. | Shape | Application |
---|---|---|---|---|---|
900 | 5.0 | 24×7.0/6.2×13(15,20) | 64 | Z3T/Z3T-M (conical) | Granite |
1000 | 5.0 | 24×7.0/6.2×13(15,20) | 70 | Z3T/Z3T-M (conical) | Granite |
1200 | 5.5 | 24×7.4/6.6×13(15,20) | 80 | Z3TZ3T-M (conical) | Granite |
1400 | 6.0 | 24×8.0/7.2×13(15,20) | 92 | Z3T/Z3T-M (conical) | Granite |
1400 | 6.5 | 24×8.4/7.6×13(15,20) | 92 | Z3T/Z3T-M (conical) | Granite |
1600 | 7.2 | 24×9.2/8.4×13(15,20) | 108 | Z3T/Z3T-M (conical) | Granite |
1800 | 7.5 | 24×10/9.2×13(15,20) | 120 | Z3T/Z3T-M (conical) | Granite |
2000 | 8.0 | 24×11/10×15(20) | 128 | Z3T/Z3T-M (conical) | Granite |
2200 | 9.0 | 24×11/10×15(20) | 132 | Z3T/Z3T-M (conical) | Granite |
2500 | 9.0 | 24×12/11×20(30) | 140 | Z3T/Z3T-M (conical) | Granite |
2700 | 9.0 | 24×12/11×20(30) | 140 | Z3T/Z3T-M (conical) | Granite |
3000 | 9.3 | 24×13/12×20(30) | 160 | Z3T/Z3T-M (conical) | Granite |
3500 | 9.5 | 24×13.5/12.5×20(30) | 180 | Z3T/Z3T-M (conical) | Granite |
Other specifications are available upon request.
For different blade and stones, customized segment size and numbers will be suggested and Wanlong can supply different specifications and diameters as per customer's requirement.
